The digital self-service kiosk K7 with a 23.8-inch screen satisfies a variety of functions in retail stores such as micropayment, QR code scanning, receipt printing, and face recognition, etc.
🔸 23.8'' touch screen, fashionable and simple design with comprehensive performance
🔸 80mm thermal printer with auto cutter, supporting 150mm speedy printing
🔸 Rapid QRcode scanner, providing speedy experience in scanning QR code and commodity code
🔸 Functional EFT-POS, supports multiple self-service payment methods
🔸 Flexible fit for multiple application scenarios
🔸 Cases: Widely used in AEON and JD.com supermarkets
.jpg "Telpo K7 self checkout kiosk with QR code scanner")
.jpg "Cloud POS system for telpo K7 kiosk")
|
Item |
Specification |
Item |
Specification |
|
OS |
Android 7.1 or above |
Face Recognition (Optional) |
Single-lens Camera, Dual-lens Camera, 3D Depth Sensing Camera |
|
Processor |
Dual-Core 1.8GHz+ Quad-Core 1.4GHz |
Communications |
WiFi/Bluetooth/Ethernet ○LTE |
|
Memory |
4GB DDR, 16GB eMMC, Ext. TF card slot |
Peripheral Ports |
2 USB Host, 1 RJ45, 1 Micro USB |
|
Display |
23.8-inch, 1080*1920 |
Audio |
Digital Audio Speaker |
|
Thermal Printer |
Paper Width 80mm, Φ80mm, with auto cutter |
Power Supply |
24V/5A |
|
Contactless Card Reader(Optional) |
ISO14443 Type A/B, Mifare, ISO18092 Compliant |
Stand (Optional) |
Check-Out Desk, Floor-stand, Wall-mounting Bracket |
|
Payment (Optional) |
TPS900: All-in-One EFT POS Integrated |
Dimensions (mm) |
370 (L)*113 (W)*814 (H) |
|
1D/2D Barcode Scanner (Optional) |
Small Window, Large Window |
Certification |
CE |
